TOP FEATURES
- Fuel injected 963 cc engine (90 HP/64 lbs/ft)
- Width: 64"
- Tires Front and Rear : 29" with rim beadlock
- Continuously Variable Transmission of CVTech-IBC
- QUADLINK trailing arm independant rear suspension with fully adjustable gas shocks
- RIDEVISION LED headlights/taillights with integrated turn signals
- Pulse color digital gauge with Bluetooth indicator
- Electric Power Steering (EPS)
- Ground Clearance : 12.2"
- 3500 lbs winch
- Roof and half doors includes
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: V-Twin cylinder, 4-strokes, 8-valves
- Displacement: 963 cc
- Bore & Stroke: 91 mm x 74 mm (3,5 x 2,91 in)
- Compression: 10.8:1
- Engine management: Fuel injected engine
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 3020 x 1 635 x 1 850 mm (119 x 64 x 73 in)
- Wheelbase: 2 285 mm (90 in)
- Ground clearance: 340 mm (13.4 in)
- Minimum turning diameter: 5500 mm (216 in)
- Fuel tank capacity: 36.5 L (9,6 gal)
- Net weight: 710 kg (1565.3 lbs)
- Rear box capacity: 100 kg (220 lbs)
- Transmission
- CV-Tech IBC clutch system: Variable transmission.
- Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, locking front differential
- Wheels
- Front wheels: Aluminium alloy (14 x 7 in)
- Rear wheels: Aluminium alloy (14 x 8 in)
- Front tires: AT 29 x 9-14
- Rear tires: AT 29 x 11-14
- Suspension and steering
- Front suspension: Double A-arm, independent suspension. High pressure gas shock absorber, compression and rebound adjustable
- Front travel: 340 mm (13,4 in)
- Rear suspension: QUADLINK™ trailing arm independent suspension. High pressure gas shock absorber, compression and rebound adjustable
- Rear travel: 395 mm (15,2 in)
- Steering: Electric Power Steering (EPS)
- Brakes
- Brakes: Front and rear brake disc system
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
