TOP FEATURES
- Fuel injected 963 cc engine
- Gas adjustable shock absorbers
- Continuously Variable Transmission of CVTech- IBC
- Electric Power Steering (EPS)
- 3500 lbs winch
- Roof and half-doors included
- 14″ aluminum alloy wheels
- Digital display dashboard with full instrumentation
- 12V outlet and USB charging port
- Mirrors
- LED headlight with integrated turn signals
-
EASY protection plan available
- Cargo box with cover
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: V-twin, 4-stroke, liquidcooled, 8 valves, SOHC
- Displacement: 963 cc
- Bore & Stroke: 91 mm x 74 mm (3,5 x 2,91 in)
- Compression: 10.8:1
- Engine management: Fuel injected engine, With management mode
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 3065 x 1524 x 1 1870mm (120.6 x 60 x 73.6 in)
- Wheelbase: 2286 mm (90 in)
- Ground clearance: 305 mm (12 in)
- Minimum turning diameter: 5250 mm (207 in)
- Net weight: 660 kg (1455 lbs)
- Fuel tank capacity: 37 L (9.77 gal)
- Rear box capacity: 150 kg (330 lbs)
- Transmission
- CV-Tech IBC clutch system: variable transmission.
- Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, locking front differential
- Wheels
- Front wheels: Aluminum alloy (14 x 7 in)
- Rear wheels:Aluminum alloy (14 x 8 in)
- Front tires: 27 x 9.00 - 14 8PR
- Rear tires: 27 x 11.00 - 14 8PR
- Suspension and direction
- Front suspension: Double A-arm, independent suspension.
- Front travel: 307 mm ( 12.1 in )
- Rear suspension:Double A link rod suspension
- Rear travel: 317.5 mm (12.5 in)
- Steering: Adaptive Electric Power Steering (EPS)
- Brakes
- Front and rear brake disc system
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
