TOP FEATURES
5 year warranty
- 292cc
- Slipper clutch
- Max Power: 28 HP(ps)/8750 rpm
- Seat height: 795 mm
- Inverted front forks
- Available colours: Athens Blue and Nebula Black
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
Engine
- Type: Single cylinder, 4-stroke, liquid-cooled, vertical
- Displacement: 292cc
- Bore & Stroke: 78 x 61.2 mm
- Max Power: 28 HP(ps)/8750 rpm
- Max Torque: 25.o N-m/7000 rpm
- Compression ratio: 11:1
- Clutch type: Wet, multi-plate, slipper clutch
Dimensions and Weight
- Length x width x height: 1990 x 780 x 1070 mm (78,3 x 30,7 x 42,1 in)
- Wheelbase: 1360 mm (53,5 in)
- Seat height: 795 mm (31,2 in)
- Fuel capacity: 12.5 L
- Curb weight: 151 kg (333 lbs)
Chassis/Suspension
- Rim: Front: 3.5 x 17 MT ; Rear: 4.0 x 17 MT
- Tire: Front: 110/70 R17 M ; Rear: 140/60 R17 M
- Suspension: Front: Telescopic upside down, hydraulic damping ; Rear: mono suspension, center aligned, preload adjustable
- Brake: Front: single-disc, 4-piston caliper ; Rear: single-disc, single-piston caliper
CFMOTO Warranty
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
