TOP FEATURES
- Fuel injected 580cc engine
- Continuously Variable Transmission of CVTech- IBC
- Electronic power steering (EPS)
- EASY protection plan
- 3000 lbs towing winch included
- 12″ aluminum wheels
- LED headlight with integrated turn signals
- USB & 12v power outlet
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: Single-Cylinder, liquid-cooled, 4-valves, 4-strokes
- Displacement: 580 cc
- Bore & Stroke: 91 x 89.2 mm (3.58 x 3.5 in)
- Compression: 10.7: 1
- Engine management: Fuel injected engine
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 2,235 x 1,180 x 1,390 mm (88 x 46.4 x 54.7in)
- Wheelbase: 1 480 mm (58.2 in)
- Ground clearance: 270 mm (10.6 in)
- Minimum turning radius: 3700 mm (146 in)
- Fuel tank capacity: 18 L (4.76 gal)
- Net weight: 415 kg (915 lbs)
- Rack capacity (Front/Rear): 20 kg (44 lbs) / 40 kg (88 lbs)
- Transmission
- CV-Tech IBC clutch system: Variable transmission.
- Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, electric locking differential
- Wheels
- Front wheels: Aluminum alloy (12 x 6 in)
- Rear wheels: Aluminum alloy (12 x 7.5 in)
- Front tires: AT 25 x 8-12
- Rear tires: AT 25 x 10-12
- Suspension and direction
- Front suspension: Double A-arm independant
- Front travel:160 mm (6.3 in)
- Rear suspension: Double A-arm independant
- Rear travel: 210 mm (8.2 in)
- Steering: Electonic Power Steering (EPS)
- Brakes
- Brakes: Four wheel hydraulic disc + rear wheel parking
- Protection plan
- EASY protection plan available
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
