TOP FEATURES
- Fuel injected 963cc engine
- Adjustable gas shock absorber in compression, spring rebound and preload
- Continuously Variable Transmission of CVTech- IBC
- Electric Power Steering (EPS)
- Removable rear cargo box
- HDPE skid plate assembly
- Front and rear bumpers
- 3,000 lb winch
- High strength aluminum winch armor
- Hand guard assembly with windshield
- 14″ beadlock aluminum wheels
- LED lights
- Hitch receiver
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: V-Twin cylinder, 4 strokes, 8 valves
- Displacement: 963 cc
- Bore & Stroke: 91 x 74 mm (3.6 x 2.9 in)
- Compression: 10.6: 1
- Engine management: Fuel injected engine
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 2310 x 1264 x 1420 mm (94.3 x 49.7 x 56 in)
- Wheelbase: 1 480 mm (58.2 in)
- Minimum ground clearance: 285 mm (11 in)
- Minimum turning radius: 3800 mm (149.6 in)
- Fuel tank capacity: 28 L (7,3 gal)
- Net weight: 490 kg (1080 lbs)
- Towing capacity: 396 kg (873 lbs)
- Rear box capacity: Front 20 kg (44 lbs) / Rear 40 kg (88 lbs)
- Transmission
- CV-Tech IBC clutch system: CV-Tech IBC clutch system variable transmission. Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, electric locking differential
- Wheels
- Front wheels: Aluminum alloy (14 x 7 in)
- Rear wheels: Aluminum alloy (14 x 8 in)
- Front tires: AT 27 x 9-14
- Rear tires: AT 27 x 11-14
- Suspension and steering
- Front suspension: Double A-arm, independent suspension, gas shock absorber with adjustable rebound/compression
- Front travel: 180 mm (7 in)
- Rear suspension: Independent trailing arm rear, fully adjustable gas shocks
- Rear travel: 190 mm (7.4 in)
- Steering: Electric Power Steering (EPS)
- Brakes
- Brakes: Four wheel hydraulic disc + rear wheel parking
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
