TOP FEATURES
- Fuel injected 963cc engine
- Continuously Variable Transmission of CVTech- IBC
- Electric Power Steering (EPS)
- For the comfort of the passenger; backrest, footrest and handles
- Hand protectors and mirros included
- 3500 lbs winch
- 14″ aluminum alloy wheels
- Digital display dashboard with full instrumentation
- 12V and USB outlet
- LED headlight with integrated turn signals
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: V-Twin cylinder, 4-strokes, 8-valves
- Displacement: 963 cc
- Bore and stroke: 91 x 74 mm (3.6 x 2.9 in)
- Compression: 10.6: 1
- Engine management: Fuel injected engine
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 2310 x 1264 x 1420 mm (94.3 x 49.7 x 56 in)
- Wheelbase: 1480 mm (58.2 in)
- Ground clearance: 285 mm (11 in)
- Minimum turning Radius: 3800 mm (150 in)
- Fuel tank capacity: 28 L (7.3 gal)
- Net weight: 490 kg (1080 lbs)
- Rack capacity (Front/Rear): 20 kg (44 lbs) / 40 kg (88 lbs)
- Transmission
- CV-Tech IBC clutch system: CV-Tech IBC clutch system variable transmission. Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, electric locking differential
- Wheels
- Front wheels: Aluminum alloy (14 x 7 in)
- Rear wheels: Aluminum alloy (14 x 8 in)
- Front tires: AT 27 x 9-14
- Rear tires: AT 27 x 11-14
- Suspension and steering
- Front suspension: Double A-arm, independent suspension, gas shock absorber with adjustable rebound/compression
- Front travel:180 mm (7 in)
- Rear suspension: Independent trailing arm rear, fully adjustable gas shocks
- Rear travel: 190 mm (7.4 in)
- Steering: Electric Power Steering (EPS)
- Brakes
- Brakes: Four wheel hydraulic disc + rear wheel parking
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
