ZFORCE 800 EX EPS

Photos are for illustrative purposes only.
ZFORCE 800 EX EPS LX 2022
5-year limited warranty
The ZFORCE 800 EX is an all-terrain vehicle offering miles of adventure and unforgettable experiences. Very well equipped upon purchase: roof, half doors, 3000 lbs winch, electronic power steering (EPS), side mirrors and aluminum rims.
Blue
Orange
White
360
From $16,899*
*The price indicated does not include registration fees, transportation, preparation, the cost of accessories and the installation of these. Furthermore taxes. Photos for illustrative purposes only, accessories not included. Specifications can change.

TOP FEATURES

suspension_gaz
Hydraulic Shock Absorber With 5 Spring Preload Adjustment
direction_assistee_electrique
Electric Power Steering
miroirs_leteraux
Lateral Mirrors
prise_12V
12V Plug
ambrayage_cvtech
CVTech Clutch System
5 years warranty
5-year warranty

  • Fuel injected 800cc engine (62 HP/53 ft/lb)
  • Gas adjustable shock absorbers
  • Continuously Variable Transmission of CVTech- IBC
  • Electric Power Steering (EPS)
  • 60″ wide offering increased stability
  • 3000 lb winch
  • Roof
  • Hitch towing rating: 680 kg
  • 14″ aluminum alloy wheels
  • Digital display dashboard with full instrumentation
  • 12V outlet
  • Mirrors
  • LED headlight with integrated turn signals

DOWNLOAD THE SPECS SHEET

DOWNLOAD THE OWNER MANUAL (BILINGUAL)

Specifications
  1. Engine
    • Type: V-Twin cylinder, 4 strokes, 8 valves
    • Displacement: 800 cc
    • Bore & Stroke: 91 x 61.5 mm (3.6 x 2.4 in)
    • Compression: 10.3 : 1
    • Engine management:Fuel injected engine
    • Maximum torque: 53 FT/LB @ 6000 rpm
    • Maximum power output: 62 HP / 6700 rpm
    • Cooling system: Liquid
    • Starting: Electric
    • Battery: 30 Amp
  2. Size / Weight
    • Length x width x height: 2870 x 1510 x 1830 mm (113 x 59.4 x 72 in)
    • Wheelbase: 2040 mm (80.3 in)
    • Seat height: 395 mm (15.6 in)
    • Ground clearance: 305 mm (12 in)
    • Fuel tank capacity: 27 L (7.1 gal)
    • Vehicle weight with all fluids: 595 kg (1312 lb)
    • Towing capacity: To come
    • Rear box capacity: 100 kg (220 lb)
  3. Transmission
    • CV-Tech IBC clutch system: Variable transmission. Gear box L / H / N / R / P (parking lock shift system)
    • Power train: 2WD / 4WD, electric locking differential
  4. Wheels
    • Front wheels: Aluminum alloy (14 x 7 in)
    • Rear wheels: Aluminum alloy (14 x 8 in)
    • Front tires: AT 26 x 9-14 (ABUZZ CST)
    • Rear tires: AT 26 x 11-14 (ABUZZ CST)
  5. Suspension and steering
    • Front suspension: Double arm independent suspension. Gas shock absorber with separate rebound/compression
    • Front travel: 270 mm (10.6 in)
    • Rear suspension: Double arm independent suspension. Gas shock absorber with separate rebound/compression
    • Rear travel: 260 mm (10.2 in)
    • Steering: Electric Power Steering (EPS)
  6. Brakes
    • Brakes: Front and rear brake disc system

CFMOTO Warranty

CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
