TOP FEATURES
- Fuel injected 800cc engine
- Gas adjustable shock absorbers
- Continuously Variable Transmission of CVTech- IBC
- Electric Power Steering (EPS)
- 50″ wide – perfect for trails
- 3000 lb winch
- Roof
- 14″ aluminum alloy wheels
- Digital display dashboard with full instrumentation
- 12V outlet
- Mirrors
- LED headlight with integrated turn signals
DOWNLOAD THE OWNER MANUAL (BILINGUAL)
- Engine
- Type: V-Twin Cylinder, 4-strokes, 8-valves
- Displacement: 800 cc
- Bore & Stroke: 91 x 61.5 mm (3.6 x 2.4 in)
- Compression: 10.3: 1
- Engine management:Fuel injected engine
- Cooling system: Liquid
- Starting: Electric
- Battery: 30 Amp
- Size / Weight
- Length x width x height: 2 870 x 1 270 x 1 790 mm (113 x 50 x 71 in)
- Wheelbase: 2040 mm (80.3 in)
- Ground clearance: 310 mm (12.2 in)
- Minimum turning diameter: 4750 mm (187 in)
- Fuel tank capacity: 27 L (7.1 gal)
- Net weight: 575 kg (1267 lbs)
- Rear box capacity: 150 kg (330 lbs)
- Transmission
- CV-Tech IBC clutch system: Variable transmission.
- Gear box: L / H / N / R / P (parking lock shift system)
- Power train: 2WD / 4WD, locking front differential
- Wheels
- Front wheels: Aluminum alloy (14 x 7 in)
- Rear wheels: Aluminum alloy (14 x 8 in)
- Front tires: AT 26 x 9-14
- Rear tires: AT 26 x 11-14
- Suspension and steering
- Front suspension: Double arm independent suspension. Gas shock absorber
- Front travel: 160 mm (6.3 in)
- Rear suspension: Double arm independent suspension. Gas absorber with separate adjustable rebound/compression
- Rear travel: 200 mm (7.8 in)
- Steering: Electric Power Steering (EPS)
- Brakes
- Brakes: Front and rear brake disc system
CFMOTO Canada’s standard 5-year warranty includes a 12-month manufacturer limited warranty and a 48-month powertrain limited warranty.
